GSi 8" - Page 77

Chapter 7: Parts List
Table 7-3 Auxiliary intermediate well parts list
Ref # Part #
Description
1
8081453-Y Intermediate Well Weldment - 8" Ochre
8101963-Y Intermediate Well Weldment - 10" Ochre
8120370-Y
Intermediate Well Weldment - 12" Ochre
2
GK1055 Band, Half 8" x 2" 12 Gauge Galvanized
GK1057 Band, Half 10" x 2" 12 Gauge Galvanized
GK2926 Band, Half 12" x 2" 12 Gauge Galvanized
3
8081468
Intermediate Well Gate - 8"
8081443
Intermediate Well Gate - 10" and 12"
4 8101742-Y
Intermediate Well with UHMW Top Flange
5
S-8760
Bolt, HHTB 1/2"-13 x 1-1/2" ZN Grade 5
6 MHC01055
Bearing, Radial 1.375" OD, 0.50" ID
7 S-2120
Washer, Flat 1/2" SAE ZN
8 S-8260
Nut, Nylock 1/2"-13 ZN Clear Grade 5
9 S-6606
Bolt, Flange 5/16"-18 x 3/4" ZN Clear Grade 5
10 GK1726
Clamp, Control Gate F/SCH 0.40" x 1/2"
11 S-1937
Washer, Flat 5/16" Grade 2 ZN
12 S-3611
Nut, Flange 5/16"-18 YDP Grade 2
13 S-9350
Bolt, HHCS 5/16"-18 x 1-1/4" YDP Grade 8
14 S-9088
Bolt, Carriage 5/16"-18 x 1-1/4" ZN Grade 5
15 8101976
Auxiliary Well Control Rod
16 S-9065
Bolt, Flange 3/8"-16 x 1" ZN Grade 5
17 S-7383
Nut, Nylock 3/8"-16 ZN Clear Grade 5
18
GK81518
Auxiliary Intermediate Well Back UHMW Flange - 8"
GK81349
Auxiliary Intermediate Well Back UHMW Flange - 10"
8120366
Auxiliary Intermediate Well Back UHMW Flange - 12"
19
8081448
Auxiliary Intermediate Well Front UHMW Flange - 8"
GK81348
Auxiliary Intermediate Well Front UHMW Flange - 10"
8120365
Auxiliary Intermediate Well Front UHMW Flange - 12"
20 S-8397
Pin, Spring 5/16" x 1-3/4" Plain Steel Slotted Rolled
21 GK81345
Intermediate Control Rod Spacer
22 8101977 Control Rod Extension
23 GK80532-BS
Control Pipe Coupling - Bin Silver
24 S-7149
Bolt, HHTB 5/16"-18 x 1-3/4" ZN Grade 5
25 S-7382
Nut, Nylock 5/16"-18 ZN Grade 5
PNEG-2308 Chain Loop Power Sweep
77
