GSi 8" - Page 81

Chapter 7: Parts List
Table 7-7 Bin flange parts list (center well gate side)
Ref # Part #
Description
1
GC21205
Weldment, 8" Wall Flange Top with UHMW
GC21162
Weldment, 10" Wall Flange Top with UHMW
8120391 Weldment, 12" Wall Flange Top with UHMW
2
8081420 Bottom Flange Assembly - 8"
8101747 Bottom Flange Assembly - 10"
8120316 Bottom Flange Assembly - 12"
3
S-2741 Bolt, HHCS 5/16"-18 x 1-1/2" ZN Grade 5
4
S-3611 Nut, Flange 5/16"-18 YDP Grade 2
5
Standard Bin Bolt
6
Flange Nut
Table 7-8 Bin flange parts list (opposite side)
Ref # Part #
Description
1
8081470 8" Backside Wall Flange Top Weldment
8101968 10" Backside Wall Flange Top Weldment
8120375 12" Backside Wall Flange Top Weldment
2
8081420 Bottom Flange Assembly - 8"
8101747 Bottom Flange Assembly - 10"
8120316 Bottom Flange Assembly - 12"
3
S-2741 Bolt, HHCS 5/16"-18 x 1-1/2" ZN Grade 5
4
S-3611 Nut, Flange 5/16"-18 YDP Grade 2
5
Standard Bin Bolt
6
Flange Nut
PNEG-2308 Chain Loop Power Sweep
