Chapter 7: Parts List
Table 7-9 Backshield with two augers parts list (24'-30' Bins)
Ref # Part #
Description
1
GK81463
Backshield - 10" x 24' Bin - Springland Wheel
GK81464
Backshield - 10" x 27' Bin - Springland Wheel
GK81465
Backshield - 10" x 30' Bin - Springland Wheel
2
GK81395
Backshield Wiper - 24' Bin - Springland
GK81498
Backshield Wiper - 27' Bin - Springland
GK81488
Backshield Wiper - 30' Bin - Springland
3 GK80534
Wiper Retainer - Extension - 24'-33' Bins
4
GK81397
Wiper Retainer - 24' Bin - Springland
GK81499
Wiper Retainer - 27' Bin - Springland
GK81500
Wiper Retainer - 30' Bin - Springland
5
GK81400
Wiper Retainer - Wheel Extension
6 GK81398
Wiper Retainer - Wheel Mount
7 GK81399
Backshield Wiper - Wheel Extension
8 GK81396
Backshield Wiper - Wheel Mount
9 S-7470
Bolt, Flange 5/16"-18 x 1" ZN Grade 5
10 S-845
Washer, Flat 5/16" USS ZN
11 S-7382
Nut, Nylock 5/16"-18 ZN Grade 5
12 S-3585
Bolt, Carriage 3/8"-16 x 1" ZN Grade 5
13 S-968
Nut, Flange 3/8"-16 ZN Grade 5 Wide Flange
14 S-8135
Bolt, Flange 5/16"-18 x 1-1/4" ZN Grade 5
15 S-7391
Bolt, Carriage 3/8"-16 x 3/4" ZN Grade 5
16
GK81401
Torque Tube - 24' Bin with Springland Wheel
GK81450
Torque Tube - 27' Bin with Springland Wheel
GK81451
Torque Tube - 30' Bin with Springland Wheel
17 S-10521
Bolt, U-bolt 5/16"-18 x 1-1/4" IW x 2" IL x 3/4" TL ZN
18 GK80715
Torque Tube Bracket
19 GC21150
10" Springland Wheel Mount
20 GK80727
Flight 9" x 6' 1.500" 1/4" Weldment - Standard
21
GK81330
Flight 9" x 2' 0.125" 1/4" Weldment - 24' Bin
GK81560
Flight 9" x 3' 6.250" 1/4" Weldment - 27' Bin
GK81565
Flight 9" x 5' 1.250" 1/4" Weldment - 30' Bin
22 GK81329
Flight 9" x 2' 5.750" 1/4" Weldment
23 GK80711
Hanger Bracket Assembly - 10" HD
24 GK2222
Shaft, Connecting 2.00" OD x 11.5"
25 S-3886
Bolt, HHCS 7/16"-14 x 1-1/4" ZN Grade 5
26 S-9073
Nut, Flange 7/16"-14 ZN
27 S-7893
Bolt, HHCS 5/8"-11 x 4" YDP Grade 8
28 S-8606
Nut, Stover 5/8"-11 ZN Grade C
PNEG-2308 Chain Loop Power Sweep
