GSi 8" - Page 85

Chapter 7: Parts List
Table 7-10 Backshield with two augers parts list (33' Bins)
Ref # Part #
Description
1
GK81466 Backshield - 10" x 33' Bin Springland Wheel
2
GK81489 Backshield Wiper - 33' Bin - Springland
3
GK80534
Wiper Retainer - Extension
4
GK81501 Wiper Retainer - 33' Bin - Springland
5
GK81400
Wiper Retainer - Wheel Extension
6
GK81398
Wiper Retainer - Wheel Mount
7
GK81399
Backshield Wiper - Wheel Extension
8 GK81396
Backshield Wiper - Wheel Mount
9
S-7470 Bolt, Flange 5/16"-18 x 1" ZN Grade 5
10
S-845 Washer, Flat 5/16" USS ZN
11
S-7382 Nut, Nylock 5/16"-18 ZN Grade 5
12
S-3585 Bolt, Carriage 3/8"-16 x 1" ZN Grade 5
13
S-968 Nut, Flange 3/8"-16 ZN Grade 5 Wide Flange
14
S-8135 Bolt, Flange 5/16"-18 x 1-1/4" ZN Grade 5
15
S-7391 Bolt, Carriage 3/8"-16 x 3/4" ZN Grade 5
16
GK81452 Torque Tube - 33' Bin with Springland Wheel
17
S-10521 Bolt, U-bolt 5/16"-18 x 1-1/4" IW x 2" IL x 3/4" TL ZN
18
GK80715
Torque Tube Bracket
19
GC21150 10" Springland Wheel Mount
20
GK80727 Flight 9" x 6' 1.500" 1/4" Weldment - Standard
21
GK81569 Flight 9" x 6' 7.250" 1/4" Weldment - 33' Bin
22
GK81329 Flight 9" x 2' 5.750" 1/4" Weldment
23
GK80711
Hanger Bracket Assembly - 10" HD
24
GK2222 Shaft, Connecting 2.00" OD x 11.5"
25
S-3886 Bolt, HHCS 7/16"-14 x 1-1/4" ZN Grade 5
26
S-9073 Nut, Flange 7/16"-14 ZN
27
S-7893 Bolt, HHCS 5/8"-11 x 4" YDP Grade 8
28
S-8606 Nut, Stover 5/8"-11 ZN Grade C
31 S-7877
Bolt, HHCS 5/16"-18 x 2" ZN Grade 5
32 GK80610
Backshield Support - Mount Plate
33 GK80609
Backshield Support Bracket Assembly
PNEG-2308 Chain Loop Power Sweep
