Chapter 7: Parts List
Table 7-13 Backshield with four augers parts list (54' Bins)
Ref # Part #
Description
1
GK81471 Backshield - 10" x 54' Bin Springland Wheel
2
GK80504
Backshield Wiper - 48' Bin
3
GK80534
Wiper Retainer - Extension
4
GK80493
Wiper Retainer - 48' Bin
5
GK81400
Wiper Retainer - Wheel Extension
6
GK81398
Wiper Retainer - Wheel Mount
7
GK81399
Backshield Wiper - Wheel Extension
8
GK81396
Backshield Wiper - Wheel Mount
9 S-7470 Bolt, Flange 5/16"-18 x 1" ZN Grade 5
10
S-845 Washer, Flat 5/16" USS ZN
11
S-7382 Nut, Nylock 5/16"-18 ZN Grade 5
12 S-3585 Bolt, Carriage 3/8"-16 x 1" ZN Grade 5
13 S-968 Nut, Flange 3/8"-16 ZN Grade 5 Wide Flange
14
S-8135 Bolt, Flange 5/16"-18 x 1-1/4" ZN Grade 5
15
S-7391 Bolt, Carriage 3/8"-16 x 3/4" ZN Grade 5
16 GK81555 Torque Tube Weldment 54' Bin Extension, Springland Wheel
17 S-10521 Bolt, U-bolt 5/16"-18 x 1-1/4" IW x 2" IL x 3/4" TL ZN
18
GK80715
Torque Tube Bracket
19 GC21150 10" Springland Wheel Mount
20
GK80727 Flight 9" x 6' 1.500" 1/4" Weldment - Standard
21
GK81562 Flight 9" x 4' 4.750" 1/4" Weldment - 54' Bin
22
GK81329 Flight 9" x 2' 5.750" 1/4" Weldment
23 GK80711 Hanger Bracket Assembly - 10" HD
24 GK2222 Shaft, Connecting 2.00" OD x 11.5"
25 S-3886 Bolt, HHCS 7/16"-14 x 1-1/4" ZN Grade 5
26
S-9073 Nut, Flange 7/16"-14 ZN
27
S-7893 Bolt, HHCS 5/8"-11 x 4" YDP Grade 8
28 S-8606 Nut, Stover 5/8"-11 ZN Grade C
30
GK80768
Torque Tube Weldment 54' Bin
31 S-7877 Bolt, HHCS 5/16"-18 x 2" ZN Grade 5
32
GK80610 Backshield Support - Mount Plate
33
GK80609 Backshield Support Bracket Assembly
34
GK80725 Support Skid - 10" HD
35 2FH1038 Bolt, HHTB 1/2"-13 x 4-1/2" ZN Grade 2
36
S-2120 Washer, Flat 1/2" SAE ZN
37 S-8506 Nut, Flange 1/2"-13 ZN Grade 5
38 S-7383 Nut, Nylock 3/8"-16 ZN Clear Grade 5
39
S-8255 Bolt, FHSCS 3/8"-16 x 1-1/2" ZN
40
S-9065 Bolt, Flange 3/8"-16 x 1" ZN Grade 5
41 GK81494 Backshield Wiper - 54' Bin - Springland
42
GK81507 Wiper Retainer - 54' Bin - Springland
43
S-8315 Nut, Lock 1/2"-13 ZN Grade C
PNEG-2308 Chain Loop Power Sweep
