Chapter 7: Parts List
Table 7-15 Backshield with six augers parts list (72' Bins)
Ref # Part #
Description
1 GK81474
Backshield - 10" x 72' Bin Springland Wheel
2 GK80504
Backshield Wiper - 48' Bin
3 GK80534
Wiper Retainer - Extension
4 GK80493
Wiper Retainer - 48' Bin
5
GK81400
Wiper Retainer - Wheel Extension
6 GK81398
Wiper Retainer - Wheel Mount
7 GK81399
Backshield Wiper - Wheel Extension
8 GK81396
Backshield Wiper - Wheel Mount
9 S-7470
Bolt, Flange 5/16"-18 x 1" ZN Grade 5
10 S-845
Washer, Flat 5/16" USS ZN
11 S-7382
Nut, Nylock 5/16"-18 ZN Grade 5
12 S-3585
Bolt, Carriage 3/8"-16 x 1" ZN Grade 5
13 S-968
Nut, Flange 3/8"-16 ZN Grade 5 Wide Flange
14 S-8135
Bolt, Flange 5/16"-18 x 1-1/4" ZN Grade 5
15 S-7391
Bolt, Carriage 3/8"-16 x 3/4" ZN Grade 5
16 GK81558
Torque Tube Weldment 72' Bin Extension, Springland Wheel
17 S-10521
Bolt, U-bolt 5/16"-18 x 1-1/4" IW x 2" IL x 3/4" TL ZN
18 GK80715
Torque Tube Bracket
19 GC21150
10" Springland Wheel Mount
20 GK80727
Flight 9" x 6' 1.500" 1/4" Weldment - Standard
21 GK81330
Flight 9" x 2' 0.125" 1/4" Weldment - 72' Bin
22 GK81329
Flight 9" x 2' 5.750" 1/4" Weldment
23 GK80711
Hanger Bracket Assembly - 10" HD
24 GK2222
Shaft, Connecting 2.00" OD x 11.5"
25 S-3886
Bolt, HHCS 7/16"-14 x 1-1/4" ZN Grade 5
26 S-9073
Nut, Flange 7/16"-14 ZN
27 S-7893
Bolt, HHCS 5/8"-11 x 4" YDP Grade 8
28 S-8606
Nut, Stover 5/8"-11 ZN Grade C
29 GK81564
Flight 9" x 4' 9.500" 1/4" Weldment - 72' Bin
30 GK80768
Torque Tube Weldment - 54' Bin
31 S-7877
Bolt, HHCS 5/16"-18 x 2" ZN Grade 5
32 GK80610
Backshield Support - Mount Plate
33 GK80609
Backshield Support Bracket Assembly
34 GK80725
Support Skid - 10" HD
35 2FH1038
Bolt, HHTB 1/2"-13 x 4-1/2" ZN Grade 2
36 S-2120
Washer, Flat 1/2" SAE ZN
37 S-8506
Nut, Flange 1/2"-13 ZN Grade 5
38 S-7383
Nut, Nylock 3/8"-16 ZN Clear Grade 5
39 S-8255
Bolt, FHSCS 3/8"-16 x 1-1/2" ZN
40 S-9065
Bolt, Flange 3/8"-16 x 1" ZN Grade 5
41 GK81497
Backshield Wiper - 72' Bin - Springland
42 GK81509
Wiper Retainer - 72' Bin - Springland
43 S-8315 Nut, Lock 1/2"-13 ZN Grade C
PNEG-2308 Chain Loop Power Sweep
