7-24 GTECH Technical Training and Support Services
12. Remove Right Side Plate Assembly.
13. Remove Platen, Stripper, a
nd L/R Platen Bearings.
Figure 7-27. Remove Right Side Plate Assy, Platen, Stripper, and L/R Platen Bearings
14. Remove Fixed Blade Spring.
Figure 7-28. Remove Fixed Blade Spring
