7-26
GTECH Technical Training and Support Services
17.
Remove Knife Pivot Shaft.
18.
Remove Latch Arm Pivot
19.
Remove Fixed Blad
e Assembly
.
Figure 7-31. Remove Knife Pivot Shaft,
Latch Arm Pivot, and
Fixed Blade Assy
17
18
19
71
73
