ASR-2000 Programming Manual
14
The USB port is used for data transfers
and upgrading software. Also, it is
available for screenshot hardcopy in
association with the Hardcopy key.
Displays the setting and measured values
or menu system
Selects between standard, simple and
harmonic analysis mode
Assigned to the functions displayed on
the right side of the screen
Used to lock or unlock the front panel
keys except output key. Simply press to
lock, whilst long press to unlock.
Turns on the shift state, which enables
shortcut operations with an icon
indicated on the top status bar. The shift
state, which allows continuous shortcut
operations, is kept until another press on
shift key again.
When performing shortcut operations,
press shift key followed by another
shortcut function key. Do not press both
shift key and shortcut function key
simultaneously.
