TEST MODE FUNCTION
145
The Branch settings allow you to
make a selectable branch within the
sequence when the sequence is
running or on hold. The branch1 or
branch2 actions are enabled by
pressing the
F1
or
F2
function keys,
or by using the :TRIG:SEQ:SEL:EXEC
remote control command. After the
branch step(s) have completed the
unit will return back to the step from
which the branch was executed and
continue to run the step from where
it left off.
Determines the step termination
settings at end of the step.
The CONTI setting tells the sequence
to go to the next step.
The HOLD setting will pause the
output at the end of the step and will
only continue to the next step when
CONTI [F3] is pressed.
The END setting will end the
sequence and go to Step 0(standby
step).
Sets the synchronous code including
LL, LH, HL and HH for each step.
Sets the start and stop phase of the
AC waveform for each step. The ON
Phs setting sets the starting phase
of
the step
.
OFF Phs sets the off phase
for the
output
when the output if turned off.
It is available for AC+DC-INT and AC-INT modes only.
