ASR-2000 Series User Manual
22
External Signal
Input Connector
Synchronizing the output
frequency with this external input
signal for SYNC or outputting the
amplified external signal with this
external input signal for EXT and
ADD.
USB
USB port for controlling the ASR-
2000 remotely
Ethernet Port
The Ethernet port is used for
remote control
RS232C
Connector
The optional RS232C connector
for controlling the ASR-2000
remotely (Factory Installed
Optional 1)
GPIB Connector
(25 pins Micro-D)
The optional GPIB connector for
controlling the ASR-2000 remotely
(Factory Installed Optional 1)
