OPERATION
39
2. Remove the protective lid from the output
terminals by loosening the screw.
3. Connect the output AC power wires to the AC
output terminals.
Red Line (L)
Black Neutral (N)
Green GND ( )
L
ine
Neutral
Grou
nd
4. Cover the protective lid onto the output
terminals as the figure below shown.
