GW Instek PEL-3021 - Main Features

PEL-3000(H) User Manual
10
Main Features
Performance
 High slew rates of up to 16A/μS(PEL-3111(H))
for a fast response speed
 High capacity when used in parallel:
5250W, 1050A(262.5A) (PEL-3111(H) x 5)/
9450W, 1890A(472.5A) (PEL-3111(H) + PEL-
3211(H) x 4)
 High resolution – 16 bit
Features
 7 operating modes: CC, CV, CR, CP, CC+CV,
CR+CV, CP+CV
 Independent and parallel operation
 Fully programmable with normal and fast
sequences
 Soft start
 Dynamic mode
 OCP, OVP and other protection features
 Remote sense
 Integrated meter
 Rack-mountable
 Load booster
Interface
 USB, RS232 and GPIB
 External voltage or resistance control
 Front panel trigger out BNC
 Front panel voltage/current monitoring BNC
 Analog external control
 Rear panel voltage/current monitoring
