PEL-3000(H) User Manual
246
(CP mode).
0 Ω to 10 kΩ correspond to maximum resistance to minimum
resistance or minimum resistance to maximum resistance (CR
mode)
Current Monitor Output
10 V f.s (H or L range) and 1 V f.s (M range)
Parallel Operation Input
Signal input for one-control parallel operation
Parallel Operation Output
Signal input for one-control parallel operation
Load Boost Power Supply Control
Power on/off control signal for the load booster
Front Panel BNC Connector
TRIG OUT
Trigger output: Approx. 5V(4.5V) pulse width: Approx. 2µs, output
impedance: Approx. 500 Ω
Outputs a pulse during sequence operation and switching
operation.
I MON OUT
Current monitor output
1V(10V) f.s (H or L range) and 0.1V(1V) f.s (M range)
V MON OUT
Voltage monitor output
8V f.s.
General
Model
PEL-3021(H)
PEL-3041(H)
PEL-3111(H)
PEL-3211(H)
Input Range
90VAC～132VAC/180VAC～250VAC Single-phase
Inrush Frequency
47~63Hz
Power (max)
90VA
110VA
190VA
230VA
Inrush Current
45A Max
Insulation Resistance
Primary to input terminal: 500(1000) VDC, 20MΩ or more.
Primary to chassis: 500(1000) VDC, 20MΩ or more.
