GW Instek PSW Series Programming Manual

REMOTE CONTROL
35
ON
Turns blink ON
Return parameter 0
<NR1>Turns blink OFF
1
<NR1>Turns blink ON
Example DISP:BLIN 1
Turns blink ON.
Initiate Commands
INITiate[:IMMediate]:NAME .............................................35
INITiate[:IMMediate]:NAME
Set
Description
The INITiate command starts the TRANsient or
OUTPut trigger.
Syntax INITiate[:IMMediate]:NAME {TRANsient|OUTPut}
Parameter TRANSient
Starts the TRANsient trigger.
OUTPut
Starts the OUTPut trigger.
Example INITiate:NAME TRANient
Starts the TRANSient trigger.
Measure Commands
MEASure[:SCALar]:CURRent[:DC]...................................35
MEASure[:SCALar]:VOLTage[:DC] .................................. 36
MEASure[:SCALar]:POWer[:DC] ....................................... 36
MEASure[:SCALar]:CURRent[:DC]
Query
Description
Takes a measurement and returns the average
output current
Syntax MEASure[:SCALar]:CURRent[:DC]?
Return parameter <NRf>
Returns the current in amps.

GW Instek PSW Series Specifications

General

Ripple & Noise (CC)	≤ 3mArms
Protections	OVP, OCP, OTP
Remote Sense	Yes
Programmable	Yes
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Voltage Resolution	1mV
Current Resolution	1mA
Current Accuracy	±0.1% + 10mA
Ripple & Noise (CV)	≤1mVrms
Load Regulation (CC)	≤0.1% + 5mA
Line Regulation (CC)	≤0.1% + 5mA
Remote Interface	USB, RS232
Display	LCD
