H3C MSR 30-20 ROUTER User Manual

1-1
1 Overview
Introduction
MSR 30 Series Routers were self-developed by our company. for use on enterprise-level networks.
Depending on the network size, MSR 30 Series Routers can be either core routers on small and
medium enterprise networks, or access routers for network branches on some large-sized enterprise
networks. Therefore, MSR 30 Series Routers are suitable for the application on the carrier-level
networks, such as telecom management networks and billing networks. MSR 30 Series Routers adopt
modular design and support a wide range of optional smart interface cards (SICs) and multi-function
interface modules (MIMs). The MSR 30-16 can adopt AC and PoE, and the MSR 30-20, 30-40 and
30-60 can adopt AC, DC, and PoE.
Except the MSR 30-11 and the AC-powered MSR 30-16, the MSR 30 series routers each provide a
redundancy power system (RPS) interface to enhance the routers’ reliability. The PoE-powered routers
can remotely supply power to its powered devices (PDs).
MSR 30 series include these models:
z MSR 30-11
z MSR 30-16
z MSR 30-20
z MSR 30-40
z MSR 30-60
System Description
Fixed Interfaces
Table 1-1 Fixed interfaces of the MSR 30 series routers
Item MSR 30-11 MSR 30-16 MSR 30-20 MSR 30-40 MSR 30-60
Console 1 1 1 1 1
AUX 1 1 1 1 1
USB 0 1 2 2 2
FE 2 2 0 0 0
GE 0 0
Two
electrical
interfaces
Two
Combo
interfaces
Two
Combo
interfaces
Fixed interfaces
SA 1 0 0 0 0

H3C MSR 30-20 ROUTER Specifications

General

Brand	H3C
Model	MSR 30-20 ROUTER
Category	Network Router
Language	English
