3-9
Connecting the console cable
Follow these steps to connect the router to a console terminal:
Step 1: Select a console terminal.
It can be a standard ASCII terminal with an RS232 serial port, or more commonly, a PC.
Step 2: Connect the console cable.
Power down the router and the console terminal, connect the RS232 serial port on the console terminal
to the console port on the router through the console cable.
Verify the connection and power up the devices. The console terminal shows the startup information of
the router if the connection is correct.
Fixed Interfaces
Ethernet Interface
Ethernet interface
MSR 30 Series provide fixed Ethernet interfaces, the MSR 30-16 provide two fixed FE interfaces, the
MSR 30-20 provides two fixed GE interfaces and the MSR 30-40/30-60 provides two fixed Combo
interface. In addition, MSR 30 Series Routers provide SIC and DSIC slots.. The MSR 30-16/30-20
provides MIM slots and the MSR 30-40/30-60 provides MIM slots and DMIM slots. These SIC and MIM
slots can expand Ethernet interface card and interface module. For the expansion rules, refer to MSR
Series Routers Interface Card and Interface Module Manual. The following table describes Ethernet
interface attributes.
Table 3-5 Attributes of the Ethernet interface
Attribute Description
Connector RJ-45
Interface MDI/MDIX auto-sensing
Frame format
Ethernet_II
Ethernet_SNAP
Operating mode
10/100/1000 Mbps auto-sensing (10/100 Mbps auto-sensing for FEs)
Full duplex/half duplex
MDI (Media Dependent Interface) is a typical type of Ethernet interface provided by network adapters.
MDIX is crossover media-dependent interface, which is commonly found on a Hub or LAN switch.
Ethernet cable
1) Connecting electrical Ethernet interface cable.
Ethernet interfaces usually use category 5 twisted pair cables, as shown in the following figure:
