4-4
1) The LEDs on the front panel show that the router is operating normally.
2) The console terminal displays normally.
For local configuration, after you power on the router, you can see the startup banner. See section
257260720 “Startup Process”.
3) After completing the power-on self-test (POST), the system asks you to press <Enter>. When the
prompt appears, you may proceed to configure the router.
Startup Process
During the power-on or reboot process, the router first initializes its memory:
InitDDR
Then the router runs BootROM, and the console terminal displays the following information:
system start booting......Version 2.11
Press CTRL+D to stop auto-boot
Press <Ctrl+D> and the system will enter the basic BootROM segment menu; otherwise, the system will
enter the decompression process of the extended BootROM segment.
Enter <Ctrl+D> within 3 seconds after the “Press CTRL+D to stop auto-boot” appears, the system can
enter basic BootROM segment menu; otherwise, the system will enter the decompression process of
the extended BootROM segment.
Booting Normal Extended BootRom
Decompressing...done!
Ensure the baudrate is set to 9600bps!Starting at 0xa00000...
*******************************************************
* *
* MSR30-20 BOOTROM, Version 2.11 *
* *
*******************************************************
Copyright(c) 2004-2007
Compiled date: Apr 09 2007, 08:52:28
CPU type : MPC8349E
CPU L1 Cache : 32KB
CPU Clock Speed : 533MHz
Memory Type : DDR SDRAM
Memory Size : 256MB
Memory Speed : 266MHz
BootRom Size : 4096KB
CPLD Version is 1.00
