3-2
Installing Cabinets
For cabinet installation methods, refer to the part discussing cabinet installation.
Skip this section if you want to mount your router on the tabletop or the rack of another vendor.
Installing the Router
Install the router after you have completed the installation preparations.
The installation of the router will be respectively described below according to the positions that it will be
placed:
z Installing the router on a workbench
z Installing the router on a chassis
Installing the Router on a Workbench
In many circumstances, you may not own a 19-inch standard rack. Usually, the router will be installed on
a clean workbench. The operations are very simple, but still, you should be aware of the following items:
z Ensure the stability and well-grounding of the workbench.
z Leave a space of 10 cm (3.9 in.) around the router for heat dissipation.
z Do not place heavy objects on the router.
Installing the Router in a Rack
Dimensions
The MSR 30 Series Routers are designed to fit standard 19-inch racks. The following table describes
their dimensions.
Table 3-1 MSR 30-16/30-20/30-40/30-60 Router dimensions
Router model
Dimensions
(H × W × D) (excluding feet and rack-mounting ear)
MSR 30-11 44.2 × 442 × 360 mm (1.74 × 17.4 × 14.2 in.)
MSR 30-16 44.2 × 442 × 441.8 mm (1.74 × 17.4 × 17.39 in.)
MSR 30-20
44.2 × 442 × 441.8 mm (1.74 × 17.4 × 17.39 in.)
MSR 30-40
88.2 × 442 × 422.3 mm (3.47 × 17.4 × 16.63 in.)
MSR 30-60
132 × 442 × 421.8 mm (5.2 × 17.4 × 16.61 in.)
Installation process
Step 1: Check the grounding and stability of the rack. Use the screws to fix the mounting ears at both
sides of the front panel or the rear panel of the router.
Step 2: Put the router in a rack tray. For MSR 30-16/30-20 routers, use mounting ears on the rear panel
if no tray is available. Depending on the actual situation, slide the router along the chassis guides to an
appropriate place.
