H3C MSR 30-20 ROUTER User Manual

5-13
boot device : mottsec0
processor number : 0
host name : host
file name : main.bin
.inet on ethernet (e) : 192.168.80.10
inet on backplane (b):
host inet (h) : 192.168.80.200
gateway inet (g) :
user (u) : guest
ftp password (pw) (blank = use rsh): 123456
flags (f) : 0x80
target name (tn) :
startup script (s) :
other (o) :
Table 5-8 Ethernet parameters settings description
Parameter Description
boot device Boot device name, not allowed to be modified.
processor number Number of processors, no need to change.
file name
Name of the file to be downloaded, which must be consistent with
the actual file name. Designate a downloading path while
designating a filename; or designate a downloading path in FTP
and TFTP settings.
inet on ethernet (e)
Set it to be in the same network with TFTP/FTP server. It has
nothing to do with port IP address of the router. Separate the
mask from the IP address if a mask is needed, for example:
192.168.80.10:24.
inet on backplane (b) Backplane address, no need to set.
host inet (h) IP address of the FTP or TFTP server
gateway inet (g) Gateway IP address, no need to set.
user (u)
Username. This setting is used in FTP downloading. No need to
set in TFTP downloading.
ftp password (pw) (blank = use
rsh)
FTP downloading password. No need to set in TFTP
downloading.
flags (f)
Downloading flag. The flag is 0x0 with FTP downloading, and
0x80 with TFTP downloading.
target name (tn)
No need to set. If set, it means the target file name saved in Flash
memory. If not, the one used for the last upgrade is used.
startup script (s) No need to set.
other (o) No need to set.
