Installation Manual
H3C S3600 Series Ethernet Switches Chapter 3 Installation
3-6
5) Hold the bottom of the switch with one hand and the front part of the switch with
the other hand, and pull the switch into the cabinet gently, as shown in
Figure 3-7.
Front square-holed bracket
Front mounting ear
Rear panel
Screw 2
Rear square -holed
bracket
Rear mounting ear
Screw 1
Screw 1: Used to bear the weight
Screw 2: Used to fix rear mounting ears to rear brackets
Figure 3-7 Fix front and rear mounting ears
After the switch is pushed into the cabinet, ensure that the upper edge of rear mounting
ears is tightly contacted with the load-bearing screw, as shown in
Figure 3-8.
Rear panel
Rear square-
holed bracket
Screw 1
Rear mounting ear
Screw 1: Load-bearing screw
Figure 3-8 Effect diagram of front and rear mounting ear installation (1)
6) Fix the other end of the front mounting ears to the front brackets with screws and
captive nuts and ensure that front and rear mounting ears have fixed the switch in
the cabinet securely, as shown in
Figure 3-9.
