Installation Manual
H3C S3600 Series Ethernet Switches Chapter 5 Loading Boot ROM and Host Software
5-9
Figure 5-3 <Disconnect> and <Call> buttons
Note:
After changing terminal’s baud rate, you must disconnect and connect the terminal
emulation program to validate the new configuration.
Step 6: Press <Enter> to start program loading. The system displays the following
information:
Now please start transfer file with XMODEM protocol.
If you want to exit, Press <Ctrl+X>.
Loading ...CCCCCCCCCC
Step 7: Select [Transfer/Send File] in the HyperTerminal’s window, and in the popup
dialog box similar to
Figure 5-4 click <Browse>, select the software you need to
download, and set the protocol to XModem.
Figure 5-4 Send File dialog box
Step 8: Click <Send>. The system displays
Figure 5-5.
