1. Features 1-1
Overview
1. Features
The V606e inherits and heightens the features of the V6 series as described below.
1. Low-cost Standard Model
The V606e is a low-cost model adapted to provide the minimum necessary functions.
This compact model, just 44.0 mm thick with a simple interface, is ideal for cost reduction.
Two types with a 16-color display and an 8-step gradation white mode display are available. Only
analog switches are usable on the V606e.
2. One MJ Port Provided as Standard
Only one MJ port is provided in line with providing the minimum necessary functions.
The functions listed below can be used through MJ1.
- Card recorder
- Barcode reader
-V-I/O
- Multi-link 2
- Temperature control network/PLC2Way
-V-Link
- Ladder transfer function
- Modbus slave communication
- Printer port (serial)
* When the simulator is used, MJ1 must be selected as [Editor Port]. This means that the
functions listed above cannot be used.
3. Brightness Adjustment with Macro Command
The brightness is adjustable with the macro command BRIGHT.
Use this adjustment function together with the contrast adjustment.
4. For V606eX20
V606eX20 contains a 128 kbyte SRAM.
It can be used for purposes including the built-in clock function, history data backup, and
nonvolatile memory $L.
* The V606e is not equipped with a printer port (parallel). When connecting to a printer, use the
serial port (MJ1).
