2-4 1. Specifications
Display Function Specifications
* In addition, the following fonts are available. For more information, refer to the Reference Manual (Operation)
and the V-SFT Additional Specifications Manual.
Gothic, English/Western Europe HK Gothic, English/Western Europe HK Times, Central Europe, Cyrillic, Greek,
Turkish
Item Specifications
Display Language* Japanese
English/Western
Europe
Chinese
(traditional)
Chinese
(simplified)
Korean
Characters
1/4-size, 1-byte ANK code Latin1 ASCII code ASCII code ASCII code
2-byte 16-dot JIS #1, 2 levels −
Chinese
(traditional)
Chinese
(simplified)
Hangul
(without Kanji)
2-byte 32-dot JIS #1 level −−−−
Character Size
1/4-size: 8 × 8 dots
1-byte: 8 × 16 dots
2-byte: 16 × 16 dots or 32 × 32 dots
Enlarge: W: 1 to 8 times, H: 1 to 8 times
Number of Displayable
Characters
1/4-size 40 characters × 30 lines
1-byte 40 characters × 15 lines
2-byte 20 characters × 15 lines
Characters Properties
Display properties: Normal, reverse, blink, bold, shadow
Colors: V606eC: 16 color + blink, V606eM: Monochrome 8-grade + blink
Graphics
Lines: Line, continuous line, box, parallelogram, polygon
Circles: Circle, arc, sector, ellipse, elliptical arc
Others: Tile patterns
Graphic Properties
Line types: 6 (thin, thick, dot, chain, broken, two-dot chain)
Tile patterns: 16 (incl. user-definable 8 patterns)
Display properties: Normal, reverse, blink
Colors: V606eC: 16 color + blink, V606eM: Monochrome 8-grade + blink
Color selection: Foreground, background, boundary (line)
