1. Specifications 2-3
Specifications
Interface Specifications
Clock and Backup Memory Specifications
Drawing Environment
Item Specifications
Serial Interface for PLC Connection
(D-sub 25-pin, female)
RS-232C, RS-422/485
Asynchronous type
Data length: 7, 8 bits
Parity: Even, odd, none
Stop bit: 1, 2 bits
Baud rate: 4800, 9600, 19200, 38400, 57600 bps
Serial Interface 1 for Screen Data
Transfer/External Connection
(Modular jack, 8-pin)
RS-232C, RS-422/485 (2-wire connection)
CREC, Barcode, V-I/O, Multi-link 2,
Temperature control network/PLC2Way, V-link, etc.
Item Specifications
Battery Specification Coin-type lithium primary cell
Backup Memory SRAM 128 kbyte
Backup Time Period 5 years (ambient temperature at 25°C)
Battery Voltage Drop Detection Provided (internal memory allocated)
Calendar Accuracy Monthly deviation ±90 sec (ambient temperature at 25°C)
Item Specifications
Drawing Method Exclusive configuration software
Drawing Tool
Name of exclusive configuration software: V-SFT (Ver. 2.2.1.0 and later)
Personal computer: Pentium II 450 MHz or above recommended
OS: Windows98/Me/NT Ver.4.0/2000/XP
Capacity of hard disk required: Free space of approx. 460 Mbyte or more
(For minimum installation: approx. 105 Mbyte)
Display: Resolution 800 × 600 or above recommended
