Hakko Electronics MONITOUCH V606e - Connection (Multi-Drop)

5-2 2. 1 : n Connection (Multi-drop)
2. 1 : n Connection (Multi-drop)
One V606e is connected to multiple PLCs. (Maximum connectable PLCs: 31)
• For more information on wiring and communication settings, refer to the PLC Connection Manual.
PLC1 PLC2 PLC3 PLCn
CN1
SYSTEM
F2
F3
F4
F5
F1
POWER
Maximum length (V606e to the terminating PLC) = 500 m
RS-422/RS-485 connection
V606e
(n = 1 to 31)
