1. Specifications 2-1
Specifications
1. Specifications
General Specifications
*1 The V606e has no electrical insulation between 0 V for the input power supply and 0 V for the internal
voltage (SG), or for the communication circuit (non-insulated power system used). Take this into
account in system design.
*2 Operation for long hours at ambient temperatures of 40 to 50°C may degrade the display quality, such
as lowering contrast.
Item Specifications
Power
Supply
Rated Voltage 24 VDC
Permissible Range of Voltage
24 VDC ± 10%
*1
Permissible Momentary Power Failure Within 1 ms
Power Consumption
(Maximum Rating)
10 W or less
Rush Current 10 A, 1 ms
Physical
Environment
Ambient Temperature 0°C to +50°C
*2
Storage Ambient Temperature −10°C to +60°C
Ambient Humidity 85% RH or less (without dew condensation)
Solvent Resistance No cutting oil or organic solvent attached to the unit
Atmosphere No corrosive gas or conductive dust
Mechanical
Working
Conditions
Vibration Resistance
Vibration frequency: 10 to 150 Hz, Acceleration: 9.8 m/s
2
(1.0G)
Single amplitude: 0.075 mm, X, Y, Z: 3 directions for one hour
Shock Resistance
Pulse shape: Sine half wave
Peak acceleration: 147 m/s
2
(15G), X, Y, Z: 3 directions six times each
Electrical
Working
Conditions
Noise Resistance 1000 Vp-p (pulse width 1µs, rise time: 1 ns)
Static Electricity Discharge Resistance
Compliant with IEC61000-4-2,
contact: 6 kV, air: 8 kV
Mounting
Conditions
Grounding Grounding resistance: less than 100 Ω
Structure
Protection structure: Front panel: compliant with IP65
(when using waterproof gasket)
Rear case: compliant with IP20
Form: In a single body
Mounting procedure: Inserted in a mounting panel
Cooling System Cooling naturally
Weight Unit only: approx. 800 g
External Dimensions W × H × D (mm) 181.6 × 138.8 × 44
Panel Cut-out Dimensions (mm)
174 ×
131
Case Color Black (Munsell N2.0)
Case Material PC/PS resin (Tarflon)
+0.5
−0
+0.5
−0
