2. Models and Peripheral Equipment 1-3
Overview
Peripheral Equipment
The following options are available for using the V606e more effectively.
V-SFT (configuration software: English version)
Application software for editing display data for the MONITOUCH.
(Windows98/NT4.0/Me/2000/XP compatible)
The V606e is supported with ver. 2.2.1.0 and later.
CREC (card recorder)
The card recorder creates a backup copy of screen data or works as an external memory
storage system for memory manager and data logging functions.
REC-MCARD (memory card) compliant with JEIDA ver. 4.0
Used with the card recorder when having a backup copy of screen data or saving data on an
external medium for memory manager and data logging functions.
SRAM 256 k, 512 k, 1 M, 2 M, 4 Mbyte
FLASH ROM 256 k, 512 k, 1 Mbyte
M-CARD SFT (memory card editor)
Application software for editing data stored on a memory card, SRAM or CF card.
(Windows98/NT4.0/Me/2000/XP compatible)
V-MDD (ACPU/QnACPU/FXCPU dual port interface)
Add-on connector with two ports, specifically designed for the connector on the
MITSUBISHI’s ACPU/QnACPU/FXCPU programmer. Operability can be improved when
directly connecting the V606e to the ACPU/QnACPU/FXCPU programmer.
V-I/O (serial extension I/O)
Used as an external I/O unit for PLC. It has 16 inputs and 16 outputs.
V6-CP (screen data transfer cable) 3 m
Used for connection between the V606e and a personal computer, or a personal computer
and the card recorder (CREC).
