1-4 2. Models and Peripheral Equipment
* The devices below are not usable with the V606e.
V6-BCD (barcode reader connection cable) 3 m
Used for connection between the V606e and a barcode reader.
V6-MLT (multi-link 2 master cable) 3 m
Used for Multi-Link 2 connection between the V606e master station and the V606e slave
station.
V6-TMP (temperature controller connection cable) 3 m
Used for connection between the V606e and a temperature controller or a PLC via
PLC2Way.
MJ-D25 (MJ-to-D-sub conversion cable) 0.3 m
Used for connection between the V606e and a PLC via PLC2Way.
V606-GS (protective sheet)
This sheet protects the operation panel surface. (5 sheets/set)
V7-BT (battery for replacement)
Replacement lithium battery for the V606e.
Model Name
TC485 Terminal converter
CU-xx Communication I/F unit
V6-PT Printer cable
V6EM/4i FROM cassette
V6EM/RSi SRAM cassette
