Wireless AP Router HNW300APN2
User Manual 58
Disable Wireless
LAN Interface
Enable/Disable the Wireless LAN Interface.
Specify the WLAN Mode to 802.11b/g Mixed mode, 802.11b mode or 802.11g
mode
Configure the Wireless LAN Interface to AP, Client, WDS, AP + WDS, MESH
or AP + MESH mode
Configure the Network Type to Infrastructure or Ad hoc.
Specify the network name.
Each Wireless LAN network uses a unique Network Name to identify the
network. This name is called the Service Set Identifier (SSID). When you set
up your wireless adapter, you specify the SSID. If you want to connect to an
existing network, you must use the name for that network. If you are setting up
your own network you can make up your own name and use it on each
computer. The name can be up to 20 characters long and contain letters and
numbers.
Choose a Channel Width from the pull-down menu.
Choose a Control Sideband from the pull-down menu.
Choose a Channel Number from the pull-down menu.
Broadcast or Hide SSID to your Network.
Enable/disable the Wi-Fi Multimedia (WMM) support.
Select the Data Rate from the drop-down list
Show Active Wireless Client Table
This table shows the MAC address, transmission, receiption packet counters
and encrypted status for each associated wireless client.
Enable Mac
Clone (Single
Ethernet Client)
Enable Mac Clone (Single Ethernet Client)
Enable Universal
Repeater Mode
Acting as AP and client simultaneously
SSID of Extended
Interface
When mode is set to “AP” and URM (Universal Repeater Mode ) is enabled,
user should input SSID of another AP in the field of “SSID of Extended
Interface”. Please note, the channel number should be set to the one, used by
another AP because 8186 will share the same channel between AP and URM
interface (called as extended interface hereafter).
