Load the assembly to the carriage. and fasten the screws
The anti-crash attachment needs to be adjusted to some 0.5mm lower than the level
of the bottom of the printhead tray when reassembling in the printer
How to adjust the anti-crash attachment
1. Place one panel of acrylic on the printing table
2. Run a “Nozzle test” based on the acrylic and fine adjust up to 0.6mm
3. Click “Printing cancel” and adjust the anti-crash bar to the same level of the
acrylic panel.
4.4 Leveling adjustment
Keep the printer’s castors laid on the ground with the supports not enabled.
Use the level to measure the middle of the four edges of the platen and find out the
highest point of the platen.
Take the highest point as a reference and adjust the support screws of the other three
corners, and get to make the four edges on the same level.
Fasten the nut of the support screws to keep the whole frame steady.
4.5 Power input requirement
The printer is high power consumption equipment of 8kW.
The input power should meet with the rated value of AC voltage and 20A.
Voltage between N and PE should lower than 3V.
The specification of the power cable should be the diameter of 4 ㎡ GB.
