2. Maintenance of the mechanical parts
Lubricate the moving mechanical parts with lithium grease monthly.
X-directional Slide Way
Y-directional Slide Way
Y-directional Screw Leads
Z-directional Screw Lead
Use the lever type grease gun to eject the lubricating grease into the slide block via
the lubricating nipple assembly on the block.
Non-clean lithium grease must avoid to be used for lubrication job or it will result in
slide way and slide block damage.
3. Precision part maintenance
All precision parts must be strictly cleaned with isopropanol and lint-free tissue according to the
maintenance instructions.
Encoder Strip
Opt-electric Sensor
head height finder assembly
