HandTop HT2500UV - Printer configurations

9
basis of the stable and high precision stepping movement.
Anti-crashing attachment can effectively reduce the head-strike risks.
Self-checking on printer running malfunctions.
Double-class ink-heating automatic control guarantees the optimum viscosity
of ink for printhead continuously discharging.
Special negative pressure tank for keeping the pressure in the state of main
power-off.
More intuitive and user-friendly operating interface.
With the ability to 24hoursX7days continuous running of commercial
printing production.
4. Printer configurations
Model
HT2500UV
Printhead type
Kyocera high-performance drop-on-demand piezo heads
Printhead array
2-4PCS
Maximum resolution
1200*1200 DPI
Printing speed
(4 Printheads)
Production
4 Pass
6 Pass
8 Pass
m²/h
52
37
27
Print size
Up to 2.5m of printing width
Media type
Rigid and flexible printing media
Printed thickness
0-50 mm
Applications
glass, acrylic, wooden board, ceramic tile, metals, PVC board,
corrugated board, plastic board, etc.
Ink type
Environmental-friendly UV ink (non-VOC)
Color mode
Lc, Lm, K, C, M, Y, V, W
Support file
Adobe Postscript Level 3, PDF, JPEG, TIFF, EPS, AI
Support RIP
SeeGet, Onyx, Caldera
Computer system
Windows2000 / XP, Windows7
NET. Weight
1450kg
Dimension
1800mm [H] × 860mm [W] × 4900mm [L]
Power consumption
8kW(20A)
Noise
The A-weighted emission sound pressure level at workstations does
not exceed 60dB(A)
Radiation
cat.1
Certificate
CE，FCC
Remark. All technical configurations are subjected to change without notification.
