②Vertical Adjusting Screw
③Horizontal Adjusting Screw
4.11.1 Vertical alignment
Run the TOPJet program, click “Setup” to enter the “Printer Parameters setting”
interface. Illustrated as below.
Select the printhead vertical alignment in the drop-down-list of the alignment checking
and run printing.
Use the magnifier to observe the upper and lower parts of the small iron printed and
sees whether the two parts merge into a complete one.
Adjust the Vertical Adjusting Screw of the printhead base according to the “Heads
Vertical” calibration print and repeat the Step3.
Repeat Step2, Step3 and Step4 until they were aligned.
How to read the Vertical Calibration print
Picture A Vertical calibration print(Good)
Picture B Vertical calibration print(Bad)
