HDG3000B User manual Copyright © Qingdao Hantek Electronics Co., LTD
6
2 Product features
Product features
⚫ Frequency range(CH1/CH2)：1μHz ~ 100MHz/80MHz/60MHz/40MHz/25MHz;
⚫ Sampling rate up to 300MSa/s, 16 bits vertical resolution to ensure the accuracy of
waveform amplitude;
⚫ Double channels with equal performance, equivalent to two independent signal
sources;
⚫ Storage depth up to 2M to create more waveform cycles as well as the better
waveform details;
⚫ Rich modulation functions, supporting for AM, DSB - AM, FM, PM, ASK, FSK and
PSK, BPSK, QPSK, 3 FSK, 4 FSK, OSK and PWM, etc.;
⚫ There are more than 160 arbitrary signals such as exponential rise, exponential fall,
ECG signal, Gaussian, half orthogonality, Lorentz, dual tone multi-frequency, DC
voltage, etc.
⚫ 4.3-inch color TFT LCD screen, clear and intuitive user interface;
⚫ Built-in high resolution 80MHz frequency meter;
⚫ Standard communication interface: front USB Host and rear USB Device;
⚫ Built-in harmonic generator function with 16 harmonic frequency, output harmonic
with a specified number of times, amplitude and phase, usually used in harmonic
detection equipment or the testing of harmonic filtering equipment.
HDG3000B has 5 functions, that are arbitrary waveform generator, pulse generator,
function generator, harmonic generator, frequency meter all in one; Using DDS (direct
digital frequency synthesis) technology, which can generate stable, pure and low
distortion output signal; User-friendly interface design and keyboard layout bring users
extraordinary experience; Rich configuration interfaces can easily realize computer
control, providing more solutions to user measurement.
