Harmonic Output

value. The range is limited by the maximum output frequency of the instrument as well

as the basic waveform frequency.

⚫ Range: integers within 2 to maximum output frequency of the instrument ÷ basic

waveform frequency.

⚫ The maximum value is 16.

7.4 Set the Harmonic Type

HDG3000B can output even harmonics, odd harmonics or all orders of harmonics.

Press [Wave] > Harmonic softkey on the front panel to enter the harmonic setting

menu, and press Type softkey to select the desired harmonic type.

1. Even

Select this type and the instrument would output basic waveform and even

harmonics.

2. Odd

Select this type and the instrument would output basic waveform and odd

harmonics.

3. All

Select this type and the instrument would output basic waveform and all the

harmonics in order.

Note: The harmonics actually output is determined by the "Order" currently

specified.

7.5 Set the Harmonic Amplitude

Press [Wave] > Harmonic softkey to enter the harmonic setting menu and press

Amplitude softkey to set the amplitude of each harmonic.

1. Index:

Press this softkey to select the index number of the harmonic to be selected.

2. Amplitude:

Press this softkey to set the amplitude of the selected subharmonic. Use the

numeric keypad to input the amplitude value and then select the desired unit from

the pop-up menu, or use the direction keys and knob to modify the current value.

⚫ For the input method of amplitude value, please refer to the introduction in

"Parameter Setting Method".

⚫ The amplitude units available are Vpp and mVpp.
