HDG3000B User manual Copyright © Qingdao Hantek Electronics Co., LTD
74
other generators (set the clock source to "External) respectively. Finally, set the
output frequencies of all the generators as a same value to realize the
synchronization among multi-instruments.
13.3.3 Power On Settings
Set the configuration to be used when the instrument is powered on the next time to
Default, Last or Output OFF. The default setting is "Default".
⚫ Default: Denote the factory default settings except some parameters (such as:
Language).
⚫ Last: Include all the system parameters and output configuration, except clock
source.
⚫ Output OFF: The last setting will be used and all output will be closed.
Press [Utility] > Startup softkey to select the desired configuration type.
When [P] key is pressed to restore the default settings, this setting will not be affected.
13.3.4 Intensity
Press [Utility] > Intensity softkey and use the direction keys and the knob to change
the backlight intensity of the screen.
The ranges from 1% to 100%.
13.3.5 System Information
Press [Utility] > System Info softkey to view the information of the device (such as
model, serial number, version number, etc.).
13.3.6 Unit
Press [Utility] > Units softkey to select units of waveform parameters.
⚫ Frequency/Period - Select the period or frequency as the waveform parameter that
can be set.
⚫ Amplitude/high level - Select the amplitude or high level as the waveform
parameter that can be set.
⚫ Offset/Low Level - Select the offset or low level as the waveform parameter that
can be set.
⚫ Pulse width/duty cycle - Select the pulse width or duty cycle as the pulse
parameters that can be set.
