Store
EN
HDG3000B User manual Copyright © Qingdao Hantek Electronics Co., LTD
68
12 Store
The instrument allows the user to store the current settings state of the instrument in
internal or external storage and recall it when needed.
12.1 Store System
The instrument provides an internal memory (home disk) and an external memory (USB
disk).
Home disk: Users can save the instrument settings state to this disk in.pho format. And
the file also can be recalled.
USB disk: Available when the instrument detects external storage (front USB port).
Users can save the instrument settings state to external storage in.pho format. The
state files .pho and arbitrary waveform files .hwf in the external memory can be recalled.
The instrument settings state file includes waveform basic parameters,
Mod/Sweep/Burst parameters and counter parameters.
Press [Utility] > Store softkey to open the store interface, as shown in the figure below.
Figure 12.1 Store Interface
Note: The instrument can only identify filenames consist of English letters, number
and underscore. If other characters are used to name the file or folder, the name
might be displayed in the store and recall interface abnormally.
12.2 File Operation
Press [Utility] > Store softkey to enter File System, users can perform a series of
operations on files or directories including New, Save, Recall, Rename, Delete, and
