⚫ The phase range is from 0º to 360º and the default is 180º.
8.9 QPSK Modulation
Users can configure the instrument to "shift" its output phase between four preset
values using QPSK modulation. The rate at which the output shifts between the four
phases (called the "carrier phase" and three "modulation phases") is determined by the
internal signal level of the instrument.
8.9.1 Select QPSK Modulation
Press [Mod] > Type > QPSK softkey to enable QPSK function.
⚫ When Mod is enabled, Sweep or Burst will be disabled automatically.
⚫ After QPSK is enabled, the instrument will generate QPSK waveform with the
currently specified carrier and modulating waveforms. To avoid multiple waveform
changes, enable modulation after configuring the other modulation parameters.
8.9.2 Carrier Waveform Shape
QPSK carrier shape: Sine (default), Square, Ramp, Pulse, Arbitrary (except DC) or
Harmonic waveform.
⚫ Press [Wave] button on the front panel to select the desired carrier waveform.
⚫ Noise and DC could not be used as carrier waveform.
8.9.3 Carrier Waveform Phase
Press [Setting] > Phase softkey on the front panel and use the numeric keypad or
direction keys and knob to input the desired phase.
The available phase ranges from 0º to 360º and the default value is 0º.
8.9.4 Modulation Source
QPSK uses the internal modulation source. After enabling QPSK modulation function,
press [Mod] > Data Source softkey, and select PN15 and PN21 codes as the
modulation source. The default is PN15 code.
8.9.5 QPSK Rate
When internal modulation source is selected, press [Mod] > Rate softkey to set the rate
at which the output phase shifts between "carrier phase" and three "modulation
