HDG3000B User manual Copyright © Qingdao Hantek Electronics Co., LTD
62
10 Burst
The HDG3000B can output a waveform for a specified number of cycles, called a burst.
It supports control of burst output by internal, external or manual trigger source;
supports three kinds of burst types including N cycle, Infinite cycle and Gated. Burst is
allowed with sine, square, ramp, pulse, Harmonic, noise (allowed only in gated burst
mode) or arbitrary waveforms (except DC).
10.1 Select Burst
Press [Burst] button on the front panel to enable Burst function (the backlight of the key
goes on), and Mod or Sweep function will be automatically disabled (if currently
enabled).
To avoid multiple waveform changes, enable burst mode after configuring other
parameters.
10.2 Burst Type
This instrument could output three types of bursts, including N Cycle, Infinite Cycle and
Gate. The default is N Cycle.
Table 10.1 Table Burst type
N Cycle Burst
In N Cycle mode, the generator will output waveform with specified number of cycles
after receiving trigger signal.
Press [Burst] > Type softkey to select “N Cycle”.
