4 Quick start
4.1 General checking
Check the shipping package
After receiving the oscilloscope, please follow the following steps to check the instrument:
Check whether there is any damage caused by transportation: If the packaging cartons
or protective foam pads are seriously damaged, please keep them until the whole
machine and accessories pass the electrical and mechanical testing.
Check the accessories
The details of the accessories are provided in Appendix A: Accessories at the end of the
user manual. If you find any accessory missing or damaged, please contact the dealer
responsible for this business.
Check the machine
If you find the instrument is damaged, not working properly, or unable to pass the
performance test, please contact the dealer responsible for this business.
4.2 Appearance and dimension
Figure 4.1 Front view
