Modulation
EN
Copyright © Qingdao Hantek Electronics Co., LTD HDG3000B User manual
47
8.6.6 Hopping Frequency
The range of hopping frequency depends on the carrier waveform currently selected.
Refer to "Frequency Characteristics" in Specifications.
Press [Mod] > HopFreq softkey. Use the numeric keypad or direction keys and knob to
input the desired frequency value.
8.7 PSK Modulation
Users can configure the instrument to "shift" its output phase between two preset values
using PSK modulation. The rate at which the output shifts between the two phases
(called the "carrier phase" and the "modulation phase") is determined by the internal
signal level of the instrument or the signal level on the [FSK/Trig/Sync/Extmod]
connector on the rear panel.
8.7.1 Select PSK Modulation
Press [Mod] > Type > PSK softkey to enable PSK function.
⚫ When Mod is enabled, Sweep or Burst will be disabled automatically.
⚫ After PSK is enabled, the instrument will generate PSK waveform with the currently
specified carrier and modulating waveforms. To avoid multiple waveform changes,
enable modulation after configuring the other modulation parameters.
8.7.2 Carrier Waveform Shape
PSK carrier shape: Sine (default), Square, Ramp, Pulse, Arbitrary (except DC) or
Harmonic waveform.
⚫ Press [Wave] button on the front panel to select the desired carrier waveform.
⚫ Noise and DC could not be used as carrier waveform.
8.7.3 Carrier Waveform Phase
Press [Setting] > Phase softkey on the front panel and use the numeric keypad or
direction keys and knob to input the desired phase.
The available phase ranges from 0º to 360º and the default value is 0º.
