Event message Description
Hold function start (manual) Hold started by HOLD button
Hold function start(communication) Hold started by communication
Hold function start(DI2) Hold started by contact input (DI2)
Hold function stop(manual) Hold stopped by HOLD button
Hold function stop(communication) Hold stopped by communication
Hold function stop(DI2) Hold stopped by contact input (DI2)
Step function action (manual) Step in progress by STEP button
Step function
action(communication)
Step in progress by communication
Step function action(DI3) Step in progress by contact input (DI3)
Temperature auto-tuning start(manual)
Auto-tuning started by temperature auto-tuning button
Temperature auto-tuning
start
(communication)
Temperature auto-tuning started by communication
Temperature auto-tuning stop(manual)
Temperature auto-tuning stopped by button
Temperature auto-tuning
stop
(communication)
Temperature auto-tuning stopped by communication
Temperature auto-tuning correct power off
Temperature auto-tuning turned off correctly
Humidity auto-tuning start (manual)
Auto-tuning started by humidity auto-tuning button
Humidity auto-tuning start (communication)
Humidity auto-tuning started by communication
Humidity auto-tuning stop (manual)
Humidity auto-tuning stopped by humidity auto-tuning button
Humidity auto-tuning stop (communication)
Humidity auto-tuning stopped by communication
Humidity auto-tuning correct power off
Humidity auto-tuning turned off correctly
SD card save start Saving in SD card started
SD card save stop Saving in SD card stopped
SD card save stop (no memory) Saving in SD card stopped because of SD card removal
SD card save stop (over capacity) Saving in SD card stopped because of over capacity
SD card save stop
(exceeded the number of files)
Saving in SD card stopped when the SD storage capacity is full
(max 512 files)
Memory save start Start the saving in the internal memory
Memory save stop Stop the saving in the internal memory
Memory save stop (overcapacity)
The saving has been stopped because the internal memory
capacity has been overcome
Memory save stop
(number of files exceeded)
The saving has been stopped because the number of files produced
in the internal memory exceeded the capacity (max 512 files)
Internal memory reset Internal memory has been reset
Parameter reset The parameters have been reset
SD card paameter upload (PTN) The pattern data have been uploaded by the SD card
SD card paameter upload(PARA) The parameters have been uploaded to the SD card
SD card paameter upload(ALL)
The pattern data and parameters have been uploated by the SD card
Parameter reset (SUM ERROR) Parameters have been reset because of errors
Event history reset Event history has been reset
Error history reset Error history has been reset.
User logo upload User logo has been uploaded
User button action User button operated
User button cancellation User button cancelled
Next operation start (manual) Operation started by RUN button
PAUSE Operation stopped by STOP button
Ambient start (manual) Ambient operated manually
Ambient start(communication) Ambient operated by communication
Ambient stop(manual) Ambient operation stopped manually
Ambient stop(communication) Ambient operation stopped by communication
