Programmable Temperature & Humidity Controller
54
1. Output Type
- The selected output type is used for inputing data to recorders etc.
Output signal is 4-20mA d.c., select between PV, MV, SV.
2. Output Range
- Set the upper/lower limit value
3. Sensor Burnt-out
- Select between 0mA and 4mA.
▶ Temperature/Humidity Retransmission Output
Parameter Setting Range Default
Output Type PV, MV, SV
PV
Output Upper Limitation Value EU(0 ~ 100%) EU 100%
Output Lower Limitation Value EU(0 ~ 100%) EU 0%
Temperature Burnt out Output 0 mA, 4 mA 0 mA
[Retransmission Parameter]
Fig. 71) Retransmission Setting
