Process value
Set value
G.RPT
SEG.N=0
Power
(ON)
Program mode
RPT
G.PT
PT.NO
SEG.N
n.SSP
n.STC
n.T10
n.JC
n.T2F
n.T20
n.T1F
n.PI 1
n.TM1
n.SP1
n.PI 2
n.TM2
n.SP2
n.PI A
n.TMA
n.SPA
SEG.N=1 SEG.N=2
SEG.N=10
NP100
Process value
Output value
Display remain
time of segment
Press for
2.5 seconds
Operation
indicator mode
PT.NO=n
PT.NO=0
: It is indicated when option is ordered.
Program mode is recommended after completing the engineering mode since
the set value changes and initializes in accordance with the changes in specific
engineering mode.
Some modes are not represented in accordance with the forms, choices, and
control type of the controller.
