Rated voltage
Tolerable voltage regulation
Power consumption
100 - 240 V AC, 50 - 60 Hz
10 % of rated voltage
MAX 10 VA(6.0 W max)
9-9. Power Supply
Safety standard
9-12. Standard
Primary terminal
Primary terminal
Ground
MIN. 500 V DC 20 M
MIN. 500 V DC 20 M
MIN. 500 V DC 20 M
9-10. Insulation Resistance
Secondary terminal
Ground
Secondary terminal
9-11. Dielectric strength
E M C
Primary terminal
Primary terminal
F.G.
2300 V AC 50/60 Hz for 1 minute
2300 V AC 50/60 Hz for 1 minute
1500 V AC 50/60 Hz for 1 minute
Secondary terminal
Ground
Secondary terminal
UL, C-UL approval (UL3121-1)
EN61010-1 (1993)
Plan
EMC emission EN 50081-2 (1993)
Plan
EMC Immunity EN 50082-2 (1995)
Plan
