Hanyoung NP100 - 12. PROGRAM SETUP CHART; Input, Output, Alarm, and Control Setup Charts; PID, Auto Tuning, and Program Setup Charts; Program Segment and Time Signal Charts

NP100
8-1-1
Input setup group
Input type High limit range Low limit range High limit scale Low limit scale
8-1-6
Cntrol setup group
Fuzzy Time unit Wait zone Wait time
Power recovery
motion mode
8-1-5
Alarm setup group
Alarm-1
Alarm-2
Alarm type
Alarm dead band
Set value of alarm
Pattern ending
signal
Pattern-1:
Pattern-2:
8-1-2
Output setup group
Output type Cycle time hysteresis Preset output Max. output Min. output
8-1-8
Auto tuning
AT type AT operation
8-2-1
Program repeat
frequency
Frequency
8-2-2
Program setup
mode
Start SV
Start type
TS-1
ON time
OFF time
ON time
OFF time
TS-2
Program com-
pletion mode
8-1-7
PID setup group
Group 1
Group 2
Group 3
Group 4
ARW P
I
D
Manual reset
SV
Segment
Mode
Pattern
setup
mode
Time
signal
Time
PID segment
TS-1
TS-2
12345678910
