9-13. Function
NP100
Bias
Scaling
Filter
Pattern
Segment
PID Group
Auto Tuning
Proportional Band (P)
Integral Time (I)
Differential Time (D)
ON, OFF Control
Manual Reset
Direct/Reverse action
Emergency (Preset)
ON/OFF Hysteresis
Auto/Man
ARW
Fuzzy
Retransmission Signal
Scaling
SPS
Setup Point
Type of Alarm
Setup Range
Alarm Hysteresis
-100.0 ~ 100.0 % for measuring input range
Valid setting a correction value.
According to setup of SL-H, SL-L of measuring range,
scaling is available.
OFF, 1 ~ 120 sec.
2 Patterns
10 Segments / 1 pattern
4 Kinds
According to SV, AT is operating.
Selection STD or Low PV
0.1 % ~ 999.9 %.
OFF, 1 ~ 6000 sec.
OFF, 1 ~ 6000 sec.
Select ON-OFF control in output group.
-0.5 ~ 105.0 %.
Valid when I=OFF
Select Direct or Reverse action in output group.
-0.5 ~ 105.0 % of output value.
0.0 ~ 100.0 % of range.
Changeable by front button
AUTO, 50.0 ~ 200.0 % at the PID group.
Selection ON or OFF on the control group.
PV, SV, MV, SPS
Setting PV, SV
24 V DC 20 mA max.
2 points.
High / Low alarm, High / Low deviation alarm.
Process alarm : 0 ~ 100 % of Range.
Deviation alarm : -100 ~ 100 % of Range.
0.0 ~ 100.0 % of instrument range.
Measuring
Input
Control
Retransmission
Alarm
