5 - Operation
5.5
WARNING! If the sprayer is put aside with liquid in the main tank, all MANIFOLD valves must be closed.
WARNING! Do not let the filling hose enter the tank. Keep it outside the tank, pointing towards the filling hole. If
the hose is lowered into the tank and the water pressure drops at the water supply, chemicals may be siphoned
back and contaminate the water supply lines and source.
Tank should normally be filled 1/3 with water before adding chemi-
cals. Always follow instructions given on the chemical container!
Water is filled into the tank by removing the tank lid located at front
of sprayer tank which is accessible from platform. It is recommended
to use water as clean as possible for spraying purposes. Always fill
water through the strainer basket to prevent foreign particles from
entering the tank. An overhead tank can be used in order to obtain
high filling capacity.
Filling through tank lid
Filling of water
Liquid system
