5 - Operation
5.10
WARNING! Be careful not to slip or splash chemicals when carrying chemicals up to the tank lid!
1. Make sure the control unit is switched off.
2. Turn the bottom Suction Manifold valve handle towards “Suction
from main tank”. Turn the top Pressure Manifold valve handle
towards “Spray” and the bottom Pressure Maniflold valve towards
“Agitation”.
3. Engage pump and set to operating r.p.m. (540/1000).
4. Add the chemicals through the main tank hole.
5. When the spray liquid is well mixed, keep P.T.O. engaged so the
spray liquid is continuously agitated until it has been sprayed on the
crop.
The chemicals are filled through the tank lid - Note instructions on the chemical container!
Filling chemicals through tank lid
